ImgArticle numberLed ConsumptionLumenCut OutLight Distribution 2319.201-H3AM-350 15W 1185 lm ASTER-B ITEM NO. 2319.201-H3AM-350 Consumption: 15W Current / Voltage: 350 mA / 120VAC LED Lumen: 1185 lm Beam Angle: 20°/25°/38°/50° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.201-H3AM-500 20W 1660 lm ASTER-B ITEM NO. 2319.201-H3AM-500 Consumption: 20W Current / Voltage: 500 mA / 120VAC LED Lumen: 1660 lm Beam Angle: 20°/25°/38°/50° CCT: 3000K CRI: 90+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.201F-H3AM-350 15W 418 lm ASTER-B ITEM NO. 2319.201F-H3AM-350 Consumption: 15W Current / Voltage: 350 mA /120VAC LED Lumen: 418 lm Beam Angle: 20°~30° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.201F-H3AM-500 20W 598 lm ASTER-B ITEM NO. 2319.201F-H3AM-500 Consumption: 20W Current / Voltage: 500 mA / 120VAC LED Lumen: 598 lm Beam Angle: 20°~30° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.201Z-H3AM-350 15W 815 lm ASTER-B ITEM NO. 2319.201Z-H3AM-350 Consumption: 15W Current / Voltage: 350mA / 120VAC LED Lumen: 815 lm Beam Angle: 15°~55° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.201Z-H3AM-500 20W 1141 lm ASTER-B ITEM NO. 2319.201Z-H3AM-500 Consumption: 20W Current / Voltage: 500mA / 120VAC LED Lumen: 1141 lm Beam Angle: 15°~55° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.204L-J2AM-C2-350 15W 1454lm ASTER-B ITEM NO. 2319.204L-J2AM-C2-350 Consumption: 15W Current / Voltage: 350mA / 120 VAC LED Lumen: 1454lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.204L-J2AM-C2-500 20W 2004lm ASTER-B ITEM NO. 2319.204L-J2AM-C2-500 Consumption: 20W Current / Voltage: 500mA / 120 VAC LED Lumen: 2004lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.204L-J2AM-C4-350 15W 1454lm ASTER-B ITEM NO. 2319.204L-J2AM-C4-350 Consumption: 15W Current / Voltage: 350mA / 120 VAC LED Lumen: 1454lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.204L-J2AM-C4-500 20W 2004lm ASTER-B ITEM NO. 2319.204L-J2AM-C4-500 Consumption: 20W Current / Voltage: 500mA / 120 VAC LED Lumen: 2004lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.204L-J2AM-P2-350 15W 1454lm ASTER-B ITEM NO. 2319.204L-J2AM-P2-350 Consumption: 15W Current / Voltage: 350mA /120VAC LED Lumen: 1454lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.204L-J2AM-P2-500 20W 2004lm ASTER-B ITEM NO. 2319.204L-J2AM-P2-500 Consumption: 20W Current / Voltage: 500mA / 120 VAC LED Lumen: 2004lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.204L-J2AM-P4-350 15W 1454lm ASTER-B ITEM NO. 2319.204L-J2AM-P4-350 Consumption: 15W Current / Voltage: 350 mA / 120 VAC LED Lumen: 1454lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.204L-J2AM-P4-500 20W 2004lm ASTER-B ITEM NO. 2319.204L-J2AM-P4-500 Consumption: 20W Current / Voltage: 500 mA / 120 VAC LED Lumen: 2004lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.222-H3AM-900 36W 2735 lm ASTER-B ITEM NO. 2319.222-H3AM-900 Consumption: 36W Current / Voltage: 120VAC / 900 mA LED Lumen: 2735 lm Beam Angle: 18°/24°/36°/60° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.222-J2AM-900 36W 2735 lm ASTER-B ITEM NO. 2319.222-J2AM-900 Consumption: 36W Current / Voltage: 120VAC / 900 mA LED Lumen: 2735 lm Beam Angle: 18°/24°/36°/60° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.222F-H3AM-850 33W 1082 lm ASTER-B ITEM NO. 2319.222F-H3AM-850 Consumption: 33W Current / Voltage: 120VAC / 850 mA LED Lumen: 1082 lm Beam Angle: 25°~ 35° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.222Z-H3AM-900 36W 1882 lm ASTER-B ITEM NO. 2319.222Z-H3AM-900 Consumption: 36W Current / Voltage: 120VAC / 900 mA LED Lumen: 1882 lm Beam Angle: 16°~60° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue 2319.222Z-J2AM-900 36W 1882 lm ASTER-B ITEM NO. 2319.222Z-J2AM-900 Consumption: 36W Current / Voltage: 120VAC / 900 mA LED Lumen: 1882 lm Beam Angle: 16°~60° CCT: 3000K CRI: 95+ UGR: Finishes: Download Product Picture Dimension Instruction Manual Photometric Data Specification E-catalogue
ASTER-B ITEM NO. 2319.201-H3AM-350 Consumption: 15W Current / Voltage: 350 mA / 120VAC LED Lumen: 1185 lm Beam Angle: 20°/25°/38°/50° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.201-H3AM-500 Consumption: 20W Current / Voltage: 500 mA / 120VAC LED Lumen: 1660 lm Beam Angle: 20°/25°/38°/50° CCT: 3000K CRI: 90+ UGR: Finishes:
ASTER-B ITEM NO. 2319.201F-H3AM-350 Consumption: 15W Current / Voltage: 350 mA /120VAC LED Lumen: 418 lm Beam Angle: 20°~30° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.201F-H3AM-500 Consumption: 20W Current / Voltage: 500 mA / 120VAC LED Lumen: 598 lm Beam Angle: 20°~30° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.201Z-H3AM-350 Consumption: 15W Current / Voltage: 350mA / 120VAC LED Lumen: 815 lm Beam Angle: 15°~55° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.201Z-H3AM-500 Consumption: 20W Current / Voltage: 500mA / 120VAC LED Lumen: 1141 lm Beam Angle: 15°~55° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.204L-J2AM-C2-350 Consumption: 15W Current / Voltage: 350mA / 120 VAC LED Lumen: 1454lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes:
ASTER-B ITEM NO. 2319.204L-J2AM-C2-500 Consumption: 20W Current / Voltage: 500mA / 120 VAC LED Lumen: 2004lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes:
ASTER-B ITEM NO. 2319.204L-J2AM-C4-350 Consumption: 15W Current / Voltage: 350mA / 120 VAC LED Lumen: 1454lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes:
ASTER-B ITEM NO. 2319.204L-J2AM-C4-500 Consumption: 20W Current / Voltage: 500mA / 120 VAC LED Lumen: 2004lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes:
ASTER-B ITEM NO. 2319.204L-J2AM-P2-350 Consumption: 15W Current / Voltage: 350mA /120VAC LED Lumen: 1454lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes:
ASTER-B ITEM NO. 2319.204L-J2AM-P2-500 Consumption: 20W Current / Voltage: 500mA / 120 VAC LED Lumen: 2004lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes:
ASTER-B ITEM NO. 2319.204L-J2AM-P4-350 Consumption: 15W Current / Voltage: 350 mA / 120 VAC LED Lumen: 1454lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 90+ UGR: Finishes:
ASTER-B ITEM NO. 2319.204L-J2AM-P4-500 Consumption: 20W Current / Voltage: 500 mA / 120 VAC LED Lumen: 2004lm Beam Angle: 15°/24°/36°/60° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.222-H3AM-900 Consumption: 36W Current / Voltage: 120VAC / 900 mA LED Lumen: 2735 lm Beam Angle: 18°/24°/36°/60° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.222-J2AM-900 Consumption: 36W Current / Voltage: 120VAC / 900 mA LED Lumen: 2735 lm Beam Angle: 18°/24°/36°/60° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.222F-H3AM-850 Consumption: 33W Current / Voltage: 120VAC / 850 mA LED Lumen: 1082 lm Beam Angle: 25°~ 35° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.222Z-H3AM-900 Consumption: 36W Current / Voltage: 120VAC / 900 mA LED Lumen: 1882 lm Beam Angle: 16°~60° CCT: 3000K CRI: 95+ UGR: Finishes:
ASTER-B ITEM NO. 2319.222Z-J2AM-900 Consumption: 36W Current / Voltage: 120VAC / 900 mA LED Lumen: 1882 lm Beam Angle: 16°~60° CCT: 3000K CRI: 95+ UGR: Finishes:
